copy of SIRIO "ORIGINALE" ANTENNA GPA 66-108 - 66…108 MHz

2112203.00

SIRIO "ORIGINALE" GPA 66-108 - Antenna 66…108 MHz

81,00 €
Bruttopreis
Menge
Disponibile

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

Beschreibung

SIRIO "ORIGINALE" GPA 66-108 - Antenna 66…108 MHz

L'Antenna 1/4 λ Ground Plane lavora sui 66-108 MHz.

È realizzata interamente in alluminio non corrosivo e montato su una forte base che permette un facile e sicura installazione garantendo ottime prestazioni.

Electrical Data

  • Type : 1/4 λ Ground Plane Frequency
  • Range : 66-108 MHz tunable by diagram
  • Impedance : 50 Ω Unbalanced
  • Radiation (H-plane) : 360o Omnidirectional
  • Radiation (E-plane) : Beamwidth at -3 dB = 86o
  • Radiation angle deg. : 0o
  • Polarization : Vertical
  • Gain : 0 dBd - 2.14 dBi
  • Bandwidth at V.S.W.R. 2:1 : 6.5 MHz at 66 MHz
  • V.S.W.R. at res. freq. : ≤ 1.2 : 1 Max
  • Power : 500 Watts Feed
  • System / Position : Direct / Center
  • Connection : UHF Female

Mechanical Data

  • Materials : Aluminium, Chromed Brass, Nylon, Stainless Steel
  • Wind Load / Resistance : 54 N at 150 Km/h / 150 Km/h
  • Wind Surface : 0.05 m2
  • Height (approx.) : 1930 mm
  • Weight (approx.) : 700 gr
  • Radial Length (approx) : 1080 mm
  • Mounting Mast : ∅ 35-40 mm
